Description
Monthly payment plan available [ learn more & apply ]
Assembly, delivery & installation are NOT included in the price but are available for an additional fee.
AEC, GIS, and MCAD professionals who want to print maps, technical drawings, posters, and renders with precise, accurate line quality and crisp text.
Keep the project momentum. With radically simple solutions and the easiest PDF printing, it's easy for everyone to get great results every time. Meet deadlines with the fastest print speed in the most compact, quiet printer.
Support the work of your teams and their projects, and accelerate progress at every stage. Experience unprecedented simplicity, and the easiest PDF printing.
Functions | |
Model size | 36 in |
Print speed | 180 D/hr, 19.3 sec/D[1] |
Print technology | HP Thermal Inkjet |
Printer drivers included | PostScript Printer: Raster, PostScript and PDF drivers for Windows, AirPrint for macOS; Non-PostScript Printer: Raster drivers for Windows, AirPrint for macOS |
Print quality color (best) | Up to 2400 x 1200 optimized dpi |
Print languages | PostScript Printer: Adobe PostScript 3, Adobe PDF 1.7, HP-GL/2, HP-RTL, TIFF, JPEG, CALS G4; Non-PostScript Printer: HP-GL/2, HP-RTL, TIFF, JPEG, CALS G4 |
Number of print cartridges | 6 (C, M, Y, G, pK, mK) |
Ink types | Dye-based (C, M, Y, pK, G); pigment-based (mK) |
Line accuracy | ±0.1%[2] |
HP ePrint capability | Yes |
Connectivity, standard | Gigabit Ethernet (1000Base-T), Wi-Fi (with optional Jetdirect accessory), supporting the following standards: TCP/IP, BootP/DHCP (IPv4 only), DHCPv6, TFTP (IPv4 only), SNMP (v1, v2c, v3), Apple Bonjour Compatible, WS Discovery, Embedded Web Server (HTTP, HTTPS), IPsec, SMTP (email), Raw IP printing (9100), LPD, IPP, WS print, NTLM v2, SMBv3, SSL/TLS, 802.1X authentication (LEAP, PEAP, EAP-TLS), DFS |
Network ready | Standard |
Memory | 128 GB (file processing)[5] |
Internal Storage | 500 GB self-encrypting removeable |
Finished output handling | Sheet feed, automatic front-loading roll feed, smart roll switching[3], integrated output stacker[4], media bin, automatic horizontal cutter |
Media sizes standard (sheets, rolls) | 11 to 36 in |
Media sizes, custom | 8.3 x 11 to 36 x 48 in |
Media types | Bond and coated paper (bond, coated, heavyweight coated, super heavyweight plus matte, colored), technical paper (natural tracing, translucent bond, vellum), film (clear, matte, polyester), photographic paper (satin, gloss, semi-gloss, matte, high-gloss), backlit, self-adhesive (two-view cling, indoor paper, polypropylene, vinyl) |
Roll external diameter | 5.5 in |
Media thickness | Up to 19.7 mil |
Power | Input voltage (auto-ranging) 100-240 V (±10%), 50/60 Hz (±3 Hz), 2 A max |
Power consumption | 100 W (printing); <36 W (ready); <10 W (sleep); 0.3 W (off) |
Ecolabels | ENERGY STAR® qualified |
Energy star certified | Yes |
Operating temperature range | 41 to 95ºF |
Minimum dimensions (W x D x H) | 55 x 30 x 43 in |
Weight | Single-roll: 181 lb, dual-roll: 187 lb |
Package dimensions (W x D x H) | 58.1 x 30.2 x 31.5 in |
Package weight | Single-roll: 249 lb, dual-roll: 258 lb |
What's in the box | HP DesignJet T1600 Printer, printer stand and media bin, spindle(s)[6], printheads, introductory ink cartridges, user guide, power cords |
Software included | HP Click, HP mobile, ePrint and iOS/Android support plus the HP Smart app for mobile, HP Web Jetadmin, HP JetAdvantage Security Manager, HP SmartTracker (optional) |
Manufacturer Warranty | One-year limited hardware warranty |
pn: 3EK10A, 3EK11A, 3EK12A, 3EK13B
Designjet T 1600
